GIGABYTE RTX 3070 EAGLE OC
The GIGABYTE RTX 3070 EAGLE OC is GIGABYTE’s version of the GeForce RTX 3070. At 282 mm it’s 40 mm longer than the 242 mm reference design. It uses 1 6-pin, 1 8-pin rather than the reference 1 12-pin. Its video outputs (2 HDMI 2.1, 2 Displayport 1.4a) differ from the reference (1 HDMI 2.1, 3 Displayport 1.4a). Below you’ll find every current retailer price and the full spec sheet.
Prices update regularly and may differ at the retailer. This page contains affiliate links.
Gaming performance
Gaming score: geometric mean of in-game FPS, normalized so the RTX 5090 = 100. Render and synthetic scores are in the Benchmarks section below.
1080p Gaming
1440p Gaming
4K Gaming
The GeForce RTX 3070 scores 47.3 at 1080p, 31.8 at 1440p, and 25.8 at 4K on a scale where 100 = the fastest GPU we test (RTX 5090). These scores apply to all board versions of this chip.
Benchmarks
Standardized benchmark scores for this chip, each compared to the fastest card we track and linked to its source. They apply to every board version.
3D & gaming
Render
Compute & AI
Where to buy
Every in-stock retailer we track, cheapest first.
- AmazonCHEAPEST$399.99In stockUpdated 2026-08-06
| Retailer | Price | Availability | Updated | Buy |
|---|---|---|---|---|
| AmazonCHEAPEST | $399.99 | In Stock | 2026-08-06 | |
Specifications
GPU chip
- Chip
- GeForce RTX 3070
- Architecture
- Ampere GA104
- Process node
- Samsung 8N
- Shader cores
- 5,888
- SM count
- 46
- Texture units (TMUs)
- 184
- Render outputs (ROPs)
- 96
- RT cores
- 46 · 2nd gen
- Tensor / AI cores
- 184 · 3rd gen
Memory
- VRAM
- 8GB GDDR6
- Memory bus
- 256-bit
- Bandwidth
- 448 GB/s
- Memory speed
- 14 Gbps
- L2 cache
- 4 MB
GPU die
- Foundry
- Samsung
- Die size
- 392 mm²
- Transistors
- 17.4 billion
- Generation
- GeForce RTX 30
Display & connectivity
- Max resolution
- 7680 × 4320
- Max displays
- 4
- HDCP
- 2.3
APIs & software
- DirectX
- 12 Ultimate (12.2)
- Vulkan
- 1.3
- OpenGL
- 4.6
- OpenCL
- 3.0
- CUDA
- Compute 8.6
- Shader model
- 6.8
Platform features
- Upscaling
- DLSS 2
- Resizable BAR
- Yes
Video encoding & decoding
| Codec | Encode | Decode |
|---|---|---|
| H.264 / AVC | Supported | Supported |
| H.265 / HEVC | Supported | Supported |
| AV1 | Not supported | Supported |
| VP9 | Not supported | Supported |
Encoder: NVENC 7th gen · Decoder: NVDEC 5th gen
Board
- Boost clock
- 1725 MHz(reference)
- Base clock
- 1500 MHz
- TDP
- 220W
- Recommended PSU
- 650W
- Power connectors
- Reference design:
1 12-pinThis card: 1 6-pin, 1 8-pin
Physical
- Cooling
- Air
- Warranty
- 3 years
- Length
- Reference design:
242 mmThis card: 282 mm - Slot width
- 2 slots
- Outputs
- Reference design:
1 HDMI 2.1, 3 Displayport 1.4aThis card: 2 HDMI 2.1, 2 Displayport 1.4a
Identifiers
- ASIN
- B08KY322TH
Chip-level specs — cores, memory, die, APIs, media engine and platform features — are shared by every version of the GeForce RTX 3070. The Board, Physical and Identifier boxes are specific to this GIGABYTE variant; a struck-through value shows where it differs from the reference design.
