MSI RTX 5060 Ti VANGUARD SOC 16 GB
The MSI RTX 5060 Ti VANGUARD SOC 16 GB is MSI’s version of the GeForce RTX 5060 Ti 16GB. It’s factory-overclocked to 2,692 MHz — 120 MHz above the 2,572 MHz reference boost clock. At 337 mm it’s 96 mm longer than the 241 mm reference design. It uses 1 16-pin rather than the reference 1 8-pin. At 3 slots it’s wider than the 2-slot reference design. Below you’ll find every current retailer price and the full spec sheet.
Prices update regularly and may differ at the retailer. This page contains affiliate links.
Gaming & render performance
Gaming score: geometric mean of in-game FPS, normalized so the RTX 5090 = 100. Blender: samples/min from Blender Open Data.
1080p Gaming
1440p Gaming
4K Gaming
Blender
The GeForce RTX 5060 Ti 16GB scores 60.0 at 1080p, 43.1 at 1440p, and 33.4 at 4K on a scale where 100 = the fastest GPU we test (RTX 5090). These scores apply to all board versions of this chip.
Where to buy
Every in-stock retailer we track, cheapest first.
| Retailer | Price | Availability | Updated | Buy |
|---|---|---|---|---|
| AmazonCHEAPEST | $1,089.97 | In Stock | 2026-06-29 |  |
Specifications
GPU chip
- Chip
- GeForce RTX 5060 Ti 16GB
- Architecture
- Blackwell GB206
- Process node
- TSMC 4N
- Shader cores
- 4,608
- RT cores
- 36
- Tensor / AI cores
- 144
- Upscaling
- DLSS 4
- AV1 encode
- Yes
Memory
- VRAM
- 16GB GDDR7
- Memory bus
- 128-bit
- Bandwidth
- 448 GB/s
- Memory speed
- 28 Gbps
Board
- Boost clock
- 2572 MHz→2692 MHz
- Base clock
- 2407 MHz
- TDP
- 180W
- Recommended PSU
- 600W
- Power connectors
- 1 8-pin→1 16-pin
Physical
- Cooling
- Air
- Length
- 241 mm→337 mm
- Slot width
- 2 slots→3 slots
- Outputs
- 1 HDMI 2.1b, 3 DisplayPort 2.1b
Identifiers
- MPN
- G506T-16VGS
- ASIN
- B0F452X8N6
Chip-level specs (memory, cores, architecture) are shared across all versions of the GeForce RTX 5060 Ti 16GB. Board specs (boost clock, length, cooling) are specific to this variant.
